Description

Soudotec 56 FC Flux-Coated Bronze Brazing Rod

Universal bronze flux-coated rod for brazing ferrous and non-ferrous metals.

Characteristics

• Minimal smoke release
• Dense and porosity-free deposits
• Excellent fluidity
• Deposits suitable to plating
• Good mechanical properties
• Ideal for dirty, oily or rusty steel

Typical Applications

Ideal for brazing galvanized steel. Thin sheet metal, body work, cast iron parts. Agricultural industry, civil engineering, piping, furniture, house appliances, cast iron to steel assembling, etc.

Procedure for Use

Clean the brazing area. Chamfer heavy parts and preheat the joint. Melt the flux from the end of the rod until it becomes fluid. Melt the filler metal to adhere easier to the base metal. Allow to cool down slowly. Use a neutral flame. For very dirty parts, or when much fluidity is required, use flux Soudotec F081

Mechanical Properties

• Tensile strength: 66 000 psi (455 MPa)
• Elongation: 26 %
• Hardness (as-welded): 115 BH

Available Diameters and Package Sizes

• 3/32 (2.4 mm) – 5 Kg
