Description

Miller Venture™ 150 T with Battery, Charger and TIG Kit Package

Package includes the Venture 150 T, 400Wh Battery Pack, Charger and TIG Kit. The Venture 150 T is a lightweight and compact battery powered TIG/Stick welder with swappable battery packs engineered specifically for welding.

Features

• Portable in the shop or at the jobsite at only 27 pounds (with battery)
• Inverter technology combines best-in-class arc characteristics
• Thermal overload protection helps prevent machine damage if the duty cycle is exceeded or airflow is blocked.
• DC stick and DC TIG processes capabilities
• Simple-to-use operator interface providing only the necessary controls in a compact machine.
• Fan-On-Demand™ power source cooling system operates only when needed, reducing noise, energy use and the amount of contaminants pulled though the machine.
• Lift-Arc™ provides TIG arc initiation without the use of high frequency. Pro-Set™ eliminates the guesswork when setting weld parameters. Use Pro-Set when you want the speed, convenience and confidence of preset controls. Simply select the feature and adjust until Pro-Set appears on the display.
• Low OCV stick is a simple design that reduces the open-circuit voltage to 12–16 volts when the welding power source is not in use. This circuit design is now built into the Venture 150 S eliminating the need for add-on voltage reducers.
• Hot Start™ adaptive control provides positive arc starts without sticking.
• Stick-Stuck detects if the electrode is stuck to the part and turns the welding output off to safely and easily remove the electrode.
• Long life. Over 1,000 charge cycles under typical-use cases and with proper care.

	E6010		E7018
	Electrodes Consumed	Amps	Electrodes Consumed	Amps
3/32 x 12 in	14.49	60	13.35	90
1/8 x 14 in	8.14	90	8.02	120
5/32 x 14 in	5.52	120	5.57	140

Title	Venture™ 150 T with Battery, Charger and TIG Kit Package
Applications	Field Welding Mobile Fabrication & MRO Off-Road Process Pipe Refineries and Power Plants Stainless Steel Tube and Pipe Fabrication
Industries	Aerospace Construction & Fabrication Farm & Ranch Mining Racing, Customizing & Restoring Railcar Shipbuilding Transportation
Portability	Handle(s) Strap
Max Open-Circuit Voltage	80 VDC
Battery Charging Options	Fast: 0-95% in < 30 mins. Standard: 0-95% in < 60 mins.
Weldable Metals	Stainless Steel Steel
Current Type	DC
Weld Output	CC
Amperage Range	Stick: 20 – 150 A TIG: 10 – 160 A
Material Thickness	Steel 0.020 in. (0.5 mm) – 3/16 in. (4.8 mm)
Battery Lifespan	Over 1,000 charge cycles under typical use cases and with proper care
TIG Arc Time Per Charge	15.54 minutes at 100A 8.33 minutes at 160A
Stick Electrode Consumption Per Charge	8.021 1/8 in. 7018 at 110A 8.14 1/8 in. 6010 at 90A 13.45 3/32 in. 7018 at 80A 14.49 3/32 in. 6010 at 60A 5.79 5/32 in. 7018 at 150A 5.57 5/32 in. 6010 at 120A
Input Voltage – Machine	57.6 VDC
Input Voltage – Charger	120 V
Input Hz	50/60 Hz
Input Phase	1-Phase

TIG Package Includes:

• Venture 150 T Power Source
• 400 Wh Battery
• Battery Charger
• Shoulder Strap with Pad
• Rubber Bumpers/Feet10 ft. (3 m) work cable w/clamp & 50 mm Dinse-style connector
• 10 ft. (3 m) stick electrode holder with 50 mm Dinse-style connector
• TIG Kit for TIG welding

Full Product Data Sheet
