Description
Harris Model 3500-200-347 Single Stage Regulator
The Model 3500 is specifically designed to provide high gas flows from cylinders and to supply manifold gas systems. It is also ideal for special high flow cylinder applications such as heavy cutting and heating. All models offer dual port outlets. All models have a neoprene diaphragm
Features
- Operates on high pressure cylinders up to 3000 PSIG
- Large 2.75 in. neoprene diaphragm for improved pressure control
- 2.5 in. Brass dual scale easy-to-read gauges
- One-piece encapsulated seat design with internal filter to protect the CTFE Kel-F® seat from particulate contamination
- Equipped with a tamper-proof, self-reseating, internal high pressure safety relief valve
- Part Number: 3003517
| Model // Part Number | 3500-200-347 // 3003517 |
| Service | Air (High Pressure) |
| Max Inlet | 5,500 PSIG |
| Delivery | 0 – 200 PSIG |
| Inlet Port | CGA 347 |
| Outlet Port | 9/16″ – 18 RH |
| Cv (Flow) | 0.4 |
