Fireball Table Drill Template – 5/8″ System

This is the ultimate drill template for fabricators who want to add holes to an existing plate steel table.

The template is 24″ x 4″ and the plate itself is 1″ thick.

There’s special locating pockets and pins that will space the holes centers 1″ or 2″ away from the edge of your table.

Each hole is lined with a .625″ inner diameter hardened drill bushing.

New improved model includes extra length to accommodate more holes that lets you align it along two edges of the table (both x and y axis) at the same time

Basic Kit (FA625-DRT241-K1-BDK) Includes:

• 1x Drill Template with drill bushings
• 4x Edge alignment pins
• 2x Tacking Bolts
• 2x Spacer Rings (1/16″ height)
• 2x Spacer Rings (1/8″ height)
• 2x Spacer Rings (1/4″ height)
