Deatschwerks High-Capacity Inline Fuel Filter – 10-Micron, 100K Psi Rating (8-03-160-100K-10)

Description

Brand: DeatschWerks
Manufacturer’s Part Number: 8-03-160-100K-10
Part Type: Fuel Filters
Product Line: DeatschWerks Inline Fuel Filters
Automotive Fittings Part Number: DWK-803160100K10
UPC: 00887753537232
Fuel Filter Style: Inline
Inlet Quantity: 1
Fuel Filter Inlet Size: -10 AN
Inlet Attachment: Female straight cut O-ring
Outlet Quantity: 1
Fuel Filter Outlet Size: -10 AN
Outlet Attachment: Female straight cut O-ring
Filter Element Included: Yes
Smallest Particle Filtered: 100 microns
Filter Element Material: Stainless steel mesh
Filter Housing Material: Aluminum
Filter Housing Color: Gray
Overall Length (in.): 6.30 in.
Outside Diameter (in.): 2.130
Mounting Bracket Included: Yes
Fittings Included: Yes
Clamps Included: No
Quantity: Sold individually.
Notes: Includes two -10 AN male straight cut O-ring to -10 AN male fittings.
Description:
E85 ethanol and other blended fuels have many contaminates capable of destroying fuel injectors and pumps. DeatschWerks inline fuel filters provide an extra layer of protection with their dual-stage, magneto-mechanical elements.
In the first stage, zero flow restrictions are accomplished through magnetic filtration. This process uses a 35mm neodymium magnet at the filter inlet to trap ferrous contaminants, keeping them from destroying fuel injectors and pumps. For maximum filtration and minimum flow restrictions, DW filters use serviceable pleated 304-series stainless steel elements to capture non-ferrous materials in stage two. They’re compatible with a wide range of fuels, including pump gas, race gas, MTBE, ethanol, methanol, and diesel.
DW fuel filters are available in two bore sizes, three housing sizes, and are constructed from T6061 aluminum with -8 AN ORB inlets and outlets. Unique surge tank fuel filters that fit directly onto their popular 250iL and 350iL pumps are also available. For high temperature tolerance, incredible life spans, and excellent filtration, buy DeatschWerks inline fuel filters.
